This is a bit smart-home specific... I've long wanted to build some smart speakers with Home Assistant's voice assistant and a multi-room music solution. Sadly I could never get Snapcast work to an acceptable level, but seems there is a new kid in the block now.

Sendspin (formerly Resonate) is an open synchronized music protocol. Currently being implemented within ESPHome. A few days ago they fixed some more memory issues and seems it's getting along. Maybe we'll get an open and working multi-room audio solution added to ESPHome soon.

I got it working on both an ESP32-S3 and an old ESP32 (with PSRAM). It's got nice features like the title, artist, album and cover art being transferred so we can just display that on a small TFT. And it's just about starting to work well enough. Now they need to finalize it, get some more things changed around in ESPHome and I can finally assemble some synced speakers for the kitchen and livingroom. Yay!

Seems it's early days for the server-side of it as well. We got support by Music Assistant. Other than that the (few) libraries warn they're still more or less just a tech demo. So as of now this is somewhat limited to tinkerers, but IMO looking really promising.

• https://esphome.io/
• https://www.music-assistant.io/
• https://www.sendspin-audio.com/
• https://github.com/esphome/esphome/pull/12284 (plus a bunch of related PRs)

Builder: @[email protected]

Components:

• ESP32-S3-Zero with RGB LED. I've selected it over more energy efficient ESP32-C6 because bigger chip looks better, and it's placed symmetrically.
• two CR1220 3V batteries.
• copper wire from Ethernet cable (single-strand obviously).
• lead-free solder (it's a ring, don't wear lead on your fingers).
• hot glue gun, because I could not make a battery holder using just wire.
• a piece of small diameter heat-shrink tube for copper wire.
• a jewellery file (optional, only needed if you actually going to wear the thing).

Instructions:

• flash the firmware first, because batteries will obstruct the USB port.
• it is recommended to file off all sharp edges on the board before you start soldering, it will be harder to smoothen the edges afterwards without scratching the copper wire.
• smoothen your wire, wrap it around some finger-size object like a tube of flux, cut the wire spiral into rings.
• solder wire rings into one side of the board, use every hole except for 5V and GND, and TX/RX on the other side.
• put the board onto your finger, measure and cut the other side of the wire rings to match your finger size, solder wire rings to the board.
• Glue two batteries together in sequence, then glue them to the top of the USB connector. Watch out for polarity - CR1220 has positive charge on the body and negative charge on the contact plate, you need to put the negative electrode onto the USB connector.
• wrap a stripped copper wire around another wire with isolation on it.
• bend both wires so that the stripped wire will go into 5V hole, and the isolated wire will go into GND and RX holes. The isolated wire is only needed as a mechanical support, because you should not solder another end of 5V wire to the TX or RX hole, or you risk frying the chip.
• add a piece of heat-shrink tube to the stripped wire. You need to make contact with the battery at the top and prevent the wire from contacting the battery at the bottom. You can try to leave a bit of isolation on the wire, but it's easier to use the tube.
• solder wires to the board.
• do not to make a common mistake of connecting 3V3 and GND together, or GND and 5V, like I did. 3V3 wire goes under the board onto the finger, GND wire goes above the board to hold the batteries.
• keep wire ends from sticking out of the mounting holes when soldering, they are going to scratch you when you wear the ring. You can file them off afterwards, but it's easier to not make them stick out in the first place.

Firmware: https://github.com/pelya/esp32-led-cycle-colors

The only thing it does is cycle LED with random colors. It shuts off power by pressing BOOT button or after 5 minutes. To turn it back on, press RESET button. There's no WiFi, Bluetooth, or LCD screen, but at least the LED is bright.

I did not measure how long will these two batteries last. When they are empty, I'll need to rip off hot glue blobs from the board, which would be pretty easy since I only put hot glue onto metallic surfaces.

And it's absolutely not waterproof, hopefully the finger grease will keep to the underside of the board and won't short the battery.

Full video: https://youtube.com/shorts/QZi4RBir2cE

I recently worked on a personal project where I wanted to trigger a sound board using a custom wake word. I had been keeping a keen eye on the work being done for local wake word detection in ESPHome and wondered if I could make use of it in this project. While ESPHome is an amazing project, I actually have a few devices flashed with it in my HA setup, it was more than I needed. This repository is the result of my efforts to make micro wake word a standalone component I could use in my own projects.

If you happen to find this useful make sure to send your thanks to those that did all the real work over at ESPHome, especially Kevin Ahrendt 😉.

And of course, here's a little video of it in action https://youtube.com/shorts/dRHSXZUriEs?si= bqvEoKjWCEACqld0

cross-posted from: https://lemmy.ml/post/22289228

It's a bit sad how deserted this community is, would love to connect more with other makers.

Let's rattle the cage a bit, who of you is here, and what are you working on?

I'll start: A wireless cryptographic keystore & signer. Keys are generated with the hardware RNG and stored AES-encrypted with the user's password, and you can request signatures via BLE.

Source: https://commons.wikimedia.org/wiki/File:ESP32-Dieshot.jpg

It's interesting how they are able to fit some much in a small space considering most of it appears to be memory.

Check the official website for specifications.

Although I am very happy with the current devices in the 2.4Ghz band, wifi-6 might be a nice improvement.

I am working on a device that appears to use a bidirectional 10-bit serial interface at 100 kHz. The master initiates the sequence by sending several 10-bit frames and slaves respond by driving the line low and responding with their own packets. This little dance occurs every 20 ms or so.

On my logic analyzer, it looks something like this:

Unfortunately, I don't own anything that natively supports 10-bit serial. All of my chips only support up to 8-bit and one even supports 9-bit (addressed) serial!

Ideally, I would like to use an ESP32-S3, mostly because I have a ton of them around and they're something I'm pretty familiar using.

Attempt 1: bitbanging serial

I attempted to just bitbang serial using several timers on the ESP32. I initially tried the high-resolution timer, but it is unable to reach a 10 us resolution and silently fails (d'oh). This is documented on their docs, but I must've missed it.

Then I tried the general purpose (GP) timer and while it's able to reach 10 us periods, it sometime skewed more than a microsecond or two! This is not acceptable for this application since there is no external clock.

Attempt 2: RMT peripheral!

After consulting the ESP32 forum, I tried the remote control transceiver (RMT) peripheral. To my surprise, this worked wonderfully. It is made for controlling remote control signals, but has numerous applications outside of that realm.

It's a pain to set this up, as it requires you to manually encode and decode pulses at a fixed period. But, this peripheral is fairly precise and accurate and can hit 10 us right on the money.

The RMT also allows you to transmit bidirectionally on the same line, using is_loop_back=true.

Here's my tester code that I used. It's ugly and definitely not ready for production, but the bones are all there. It's roughly based on the RMT NEC example on the Espressif website. It initializes the RMT with:

• a transmitter
• an encoder to convert the lower 10-bits of ushorts into pulse structures for the underlying RMT
• a loopback receiver
• an ugly decoder that performs some rounding (e.g. rounding 8 us to 10 us)

#include "freertos/FreeRTOS.h"
#include "freertos/task.h"
#include "freertos/queue.h"
#include "driver/rmt_tx.h"
#include "driver/rmt_rx.h"
#include "driver/rmt_encoder.h"

#include "esp_check.h"
#include "esp_log.h"
#include "driver/gpio.h"
#include <stdint.h>

#define SERIAL_FREQ_HZ 1000000
#define SERIAL_TX_GPIO_NUM 6
#define SERIAL_RX_GPIO_NUM 7

static const char TAG[] = "main";

static rmt_channel_handle_t tx_channel_handle = NULL;
static rmt_channel_handle_t rx_channel_handle = NULL;
static const rmt_transmit_config_t tx_config = {
  .loop_count = 0,
  .flags.eot_level = 0, // stop bit: note inverted
};
static rmt_encoder_handle_t encoder = NULL;

const static rmt_symbol_word_t bits[2] = {
  // inverted!
  // might be a bug: duration=0 does not work
  /* 0 */ {
    .level0 = 1,
    .duration0 = 5,
    .level1 = 1,
    .duration1 = 5,
  },
  /* 1 */ {
    .level0 = 0,
    .duration0 = 5,
    .level1 = 0,
    .duration1 = 5
  },
};


// #define RMT_ENCODING_RESET 0

typedef struct {
  rmt_encoder_t base;
  rmt_encoder_t *copy_encoder;
  rmt_symbol_word_t start_bit;
  int state;
  rmt_symbol_word_t end_bit;
} rmt_curtis_encoder_t;


static size_t rmt_encode_curtis(rmt_encoder_t *encoder, rmt_channel_handle_t channel, const void *primary_data, size_t data_size, rmt_encode_state_t *out_state) {
  rmt_curtis_encoder_t *curtis_encoder = __containerof(encoder, rmt_curtis_encoder_t, base);
  rmt_encode_state_t session_state = RMT_ENCODING_RESET;
  rmt_encode_state_t state = RMT_ENCODING_RESET;
  size_t encoded_symbols = 0;

  uint16_t raw = *((uint16_t *)primary_data);
  rmt_encoder_t *copy_encoder = curtis_encoder->copy_encoder;

  switch(curtis_encoder->state) {
    case 0: // send start bit
      encoded_symbols += copy_encoder->encode(copy_encoder, channel, &curtis_encoder->start_bit, sizeof(rmt_symbol_word_t), &session_state);
      if (session_state & RMT_ENCODING_COMPLETE) {
        curtis_encoder->state = 1; // go to next state
      }
      if (session_state & RMT_ENCODING_MEM_FULL) {
        state |= RMT_ENCODING_MEM_FULL;
        goto out;
      }

    // fall-through
    case 1: // send data symbols
      for(int i = 0; i < 10; i++) {
        // iterate through bits in data
        bool bit = (raw >> i) & 0b1;
        rmt_symbol_word_t symbol = bits[bit];
        encoded_symbols += copy_encoder->encode(copy_encoder, channel, &symbol, sizeof(rmt_symbol_word_t), &session_state);

        if (session_state & RMT_ENCODING_MEM_FULL) {
          state |= RMT_ENCODING_MEM_FULL;
          goto out;
        }
      }
      // data is encoded :)
      curtis_encoder->state = 2;
      state |= RMT_ENCODING_COMPLETE;

    // fall through
    case 2: // end end bit
      encoded_symbols += copy_encoder->encode(copy_encoder, channel, &curtis_encoder->end_bit, sizeof(rmt_symbol_word_t), &session_state);
      if (session_state & RMT_ENCODING_COMPLETE) {
        curtis_encoder->state = RMT_ENCODING_RESET; // go to next state
        state |= RMT_ENCODING_COMPLETE;
      }
      if (session_state & RMT_ENCODING_MEM_FULL) {
        state |= RMT_ENCODING_MEM_FULL;
        goto out;
      }
      // all done!
  }

out:
  *out_state = state;
  return encoded_symbols;
}

static esp_err_t rmt_del_curtis_encoder(rmt_encoder_t *encoder) {
  rmt_curtis_encoder_t *curtis_encoder = __containerof(encoder, rmt_curtis_encoder_t, base);
  rmt_del_encoder(curtis_encoder->copy_encoder);
  free(curtis_encoder);
  return ESP_OK;
}

static esp_err_t rmt_curtis_encoder_reset(rmt_encoder_t *encoder) {
  rmt_curtis_encoder_t *curtis_encoder = __containerof(encoder, rmt_curtis_encoder_t, base);
  rmt_encoder_reset(curtis_encoder->copy_encoder);
  curtis_encoder->state = RMT_ENCODING_RESET;
  return ESP_OK;
}

esp_err_t rmt_new_curtis_encoder(rmt_encoder_handle_t *out_encoder) {
  rmt_curtis_encoder_t *curtis_encoder = calloc(1, sizeof(rmt_curtis_encoder_t));
  // TODO: error check
  curtis_encoder->state = 0;
  curtis_encoder->base.encode = rmt_encode_curtis;
  curtis_encoder->base.del = rmt_del_curtis_encoder;
  curtis_encoder->base.reset = rmt_curtis_encoder_reset;

  rmt_copy_encoder_config_t copy_encoder_config = {};
  rmt_new_copy_encoder(&copy_encoder_config, &curtis_encoder->copy_encoder);

  // construct start, end bit
  curtis_encoder->start_bit = bits[0];
  curtis_encoder->end_bit = bits[1];

  *out_encoder = &curtis_encoder->base;

  return ESP_OK;

}

static bool rmt_rx_done_callback(rmt_channel_handle_t channel, const rmt_rx_done_event_data_t *edata, void *user_data)
{
    BaseType_t high_task_wakeup = pdFALSE;
    QueueHandle_t receive_queue = (QueueHandle_t)user_data;
    // send the received RMT symbols to the parser task
    xQueueSendFromISR(receive_queue, edata, &high_task_wakeup);
    return high_task_wakeup == pdTRUE;
}

static unsigned int round_duration(unsigned int duration) {
  int mod = duration % 10;

  if (mod == 0) {
    return duration;
  }

  if (mod >= 5) {
    return duration + (10 - mod);
  }
  return duration - mod;
}
static int extract_level(uint16_t *data, int index, const unsigned int level, const unsigned int duration) {
  if (level == 1) {
    // this is inverted, so this is a zero. we can just increase index
    return index + duration / 10;
  }

  for(int i = 0; i < duration / 10; i++) {
    *data |= 1 << index;
    index++;
  }

  return index;
}

static void round_symbol_word(rmt_symbol_word_t *word) {
  word->duration0 = round_duration(word->duration0);
  word->duration1 = round_duration(word->duration1);
}

uint16_t sequence[] = {
  0x3BA,
  0x2,
  0x2,
  0x3E2,
  0x2,
  0x102,
  0x15A
};

uint16_t master_seq[] = {
  0x2E8,
  0x202,
  0x002,
  0x3E2,
  0x002,
  0x002,
  0x05A
};

static void parse_frame(rmt_symbol_word_t *rmt_symbols, size_t symbol_num)
{
    // printf("frame start---\r\n");
    uint16_t data = 0;
    int data_idx = 0;

    for (size_t i = 0; i < symbol_num; i++) {
      rmt_symbol_word_t symbol = rmt_symbols[i];
      // round_symbol_word(&symbol);

      data_idx = extract_level(&data, data_idx, symbol.level0, symbol.duration0);
      data_idx = extract_level(&data, data_idx, symbol.level1, symbol.duration1);


      // printf("{%d:%d},{%d:%d}\r\n", symbol.level0, symbol.duration0,
      //         symbol.level1, symbol.duration1);

    }

    while(data_idx < 14) {
      // stick in remaining bits
      data |= 1 << data_idx;
      data_idx++;
    }

    data = (data >> 1) & 0b1111111111;

    if (data == 0x5A) {
      for(uint16_t i = 0; i < 7; i++) {
        rmt_transmit(tx_channel_handle, encoder, (void *)&sequence[i], sizeof(uint16_t), &tx_config);
      }
      // rmt_tx_wait_all_done(tx_channel_handle, 5);

    }
    // ESP_LOGI(TAG, ">> data = %x", (data >> 1) & 0b1111111111);
    // // printf("---frame end: ");
}


static void parse_all_frames(rmt_symbol_word_t *rmt_symbols, size_t symbol_num) {
  // breaks up frames into smaller ones

  int current_duration = 0;
  size_t current_size = 0;

  rmt_symbol_word_t *start = NULL;

  for(size_t i = 0; i < symbol_num; i++) {
    rmt_symbol_word_t *word = &rmt_symbols[i];

    if (start == NULL) {
      start = word;
    }

    round_symbol_word(word);
    current_duration += word->duration0 + word->duration1;
    current_size++;

    if (current_duration / 10 >= 12) {
      // ship it
      parse_frame(start, current_size);

      current_duration = 0;
      current_size = 0;
      start = NULL;
    }
  }

  if (start != NULL) {
    parse_frame(start, current_size);
  }
}

void app_main() {
  ESP_LOGI(TAG, "create rmt tx channel");

  // init rx channel
  // very important to initialize rx before tx, see: https://github.com/espressif/esp-idf/issues/11768
  rmt_rx_channel_config_t rx_channel_config = {
    .clk_src=RMT_CLK_SRC_DEFAULT,
    .gpio_num=SERIAL_TX_GPIO_NUM,
    .mem_block_symbols=64,
    .resolution_hz=SERIAL_FREQ_HZ,
    .flags.invert_in=true,
    .flags.with_dma=false,
    .flags.io_loop_back=true,
  };
  ESP_ERROR_CHECK(rmt_new_rx_channel(&rx_channel_config, &rx_channel_handle));

  // init tx channel
  rmt_tx_channel_config_t tx_channel_config = {
    .clk_src=RMT_CLK_SRC_DEFAULT,
    .gpio_num = SERIAL_TX_GPIO_NUM,
    .mem_block_symbols=64,
    .resolution_hz=SERIAL_FREQ_HZ,
    .trans_queue_depth=3,
    .flags.invert_out=true,
    .flags.with_dma=false,
    .flags.io_loop_back=true,
    .flags.io_od_mode=true
  };

  ESP_ERROR_CHECK(rmt_new_tx_channel(&tx_channel_config, &tx_channel_handle));

  // set gpio modes
  // gpio_set_pull_mode(SERIAL_TX_GPIO_NUM, GPIO_FLOATING);
  // gpio_set_pull_mode(SERIAL_TX_GPIO_NUM, GPIO_MODE_INPUT);
  // gpio_set_drive_capability(SERIAL_TX_GPIO_NUM, GPIO_DRIVE_CAP_0);

  // init rx queue and callbacks
  QueueHandle_t receive_queue = xQueueCreate(10, sizeof(rmt_rx_done_event_data_t));

  rmt_rx_event_callbacks_t cbs = {
    .on_recv_done=rmt_rx_done_callback
  };
  ESP_ERROR_CHECK(rmt_rx_register_event_callbacks(rx_channel_handle, &cbs, receive_queue));

  rmt_receive_config_t receive_config = {
    .signal_range_min_ns=7*1000, // start bit only
    .signal_range_max_ns=12*10*1000 + 7*1000
  };

  // create tx encoder

  rmt_new_curtis_encoder(&encoder);

  ESP_ERROR_CHECK(rmt_enable(tx_channel_handle));
  ESP_ERROR_CHECK(rmt_enable(rx_channel_handle));

  rmt_symbol_word_t raw_symbols[64] = {0}; // more than enough
  rmt_rx_done_event_data_t rx_data;

  ESP_ERROR_CHECK(rmt_receive(rx_channel_handle, raw_symbols, sizeof(raw_symbols), &receive_config ));



  for(;;) {
    if (xQueueReceive(receive_queue, &rx_data, pdMS_TO_TICKS(10)) == pdPASS) {
        // ESP_LOGI(TAG, "received data");
        parse_all_frames(rx_data.received_symbols, rx_data.num_symbols);
          // start receive again
        ESP_ERROR_CHECK(rmt_receive(rx_channel_handle, raw_symbols, sizeof(raw_symbols), &receive_config));


        // vTaskDelay(5);
    } else {
      // for(uint16_t i = 0; i < 7; i++) {
      //   rmt_transmit(tx_channel_handle, encoder, (void *)&master_seq[i], sizeof(uint16_t), &tx_config);
      // }
    }
  }
}

Thought I'd make this community to discuss and give community help for the ESP8266 and ESP32 chips. I've been using them as a hobby for a few years and recently began working with them at work using ESP-IDF.
